Sherrill residence

Project Location:

West Jefferson, North Carolina

Residential Designer:

3DFX Solutions, Inc. Huntersville, North Carolina

Project Description:

Cricket and Phillipe Bonnetaud began designing and putting together their dream home several years ago.  So, we sat down with the clients and discussed their design and the floor plan of their new home.  We began the Construction Drawings and created the 3D model to show them what their home would eventually look like.  We prepared the drawings and got them ready for permitting and estimation and finally, get it ready for construction.  Check back soon for photos from the construction site!

Project Location:

North Carolina

Residential Designer:

3DFX Solutions Huntersville, North Carolina

Project Description:

This is one of the first projects I designed in college.  It is an atrium style house that has a strong influence from Frank Lloyd Wright.  I am a huge fan of his, so when our professor gave us the design criteria for the house, I immediately envisioned this house in my head.  It wasn't until years later that I was able to draw and render this house in my design software.  I've included an overall floor plan layout and a kitchen and master bedroom renderings showing different schemes. I hope to one day have this home built by either myself or a client that likes it as much as I do.

Project Location:

Waxhaw, North Carolina

Residential Designer:

3DFX Solutions, Inc. Huntersville, North Carolina

Project Description:

Jim Smith, a former client of ours, asked us to renovate his kitchen.  After sitting down with him, taking measurements, and working with the contractor on a couple of different designs, you see can see the final product in the rendering above. Once the 3D model was completed, we created the construction drawings for the home and CDR+A Engineers provided the engineering for the new beams that we had to install overhead, after removing some of the walls in the existing kitchen.  Stay tuned and you'll see the new kitchen take shape throughout the construction phase.  Once construction is complete, we'll post photos of the finished kitchen.

Project Location:

Waxhaw, North Carolina

Residential Designer:

3DFX Solutions, Inc.

Huntersville, North Carolina

Project Description:

Bill Goldstein, owner of Mr. Outdoor Living in South Charlotte, asked us to help created an outdoor kitchen for his clients, the Gentlesks.  After sitting down with him, taking measurements, and working with the contractor on a couple of different designs, you see can see the final product in the rendering above. Once the 3D model was completed, we created the construction drawings for the home to present to the Providence Country Club POA.  Stay tuned and you'll see the new kitchen take shape throughout the construction phase.  Once construction is complete, we'll post photos of the finished kitchen.

Project Location:

Rockwell, North Carolina

Residential Designer:

3DFX Solutions, Inc. Huntersville, North Carolina

Project Description:

Rick Sickle brought us a sketch and plan that he had in mind for his new home and we were able to take those designs and turn it into their next home.  So, we sat down with the clients and discussed their design and the floor plan of their new home.  We began the Construction Drawings and created the 3D model to show them what their home would eventually look like.  We prepared the drawings and got them ready for permitting and estimation and finally, get it ready for construction.  Check back soon for photos from the construction site!

Project Location:

Mooresville, North Carolina

Residential Designer:

3DFX Solutions, Inc. Huntersville, North Carolina

Project Description:

Terry Morse, a Huntersville based contractor, called us and asked us to help create a set of construction drawings for a garage in Mooresville.  The property and home were owned by Bert Jones, so we met with Bert and created the rendering you see above and began working on the construction drawings for it.  Bert wanted the garage to match his home, so we took photos of the materials on his home and developed integrated them into the model of the garage you see on this page.  Once we had the design, we created the set of construction drawings.  As soon as we have  photos of the project under construction and the finish product, we'll post them on this page so stay tuned!

Project Location:

Huntersville, North Carolina

Residential Designer:

3DFX Solutions, Inc. Huntersville, North Carolina

Project Description:

Dominique DeLaney called us to develop a new design for their outdoor deck.  The original deck that was built with the house had begun to deteriorate and not be able to support their needs.  So, we extended the deck eight feet into the back yard and added a new screened porch, centralize stair, and extended the open deck across the rear of the home.  With the grade sloping away from the home, we were able to add a substantial under deck storage area as well.

Project Location:

Huntersville, North Carolina

Residential Designer:

3DFX Solutions, Inc. Huntersville, North Carolina

Project Description:

Jeff Davis came to us after his house had been taken in a fire earlier in the year and upon rebuilding, he wanted to change a few things.  So, we sat down with Jeff and went over some designs he had drawn and developed the home you see above and below.  The front façade is a brick and stone  and the sides and rear are hardi-plank siding.  We added a two feet cantilever over the great room at the rear of the house and moved the outdoor deck near the garage and added a screened porch.  We also added a 3rd level attic space that can be turned into an entertainment space in the future.  We hope Jeff and his family will be happy in his newly renovated and re-built home for years to come.

Project Location:

Charlotte, North Carolina

Residential Designer:

3DFX Solutions, Inc. Huntersville, North Carolina

Project Description:

Sid and Bummie Nurkin wanted to add a 6'-8" addition to the back of their house as well as an office and entertainment room on the second floor of their home.  They contacted 3DFX Solutions to help design and create the design you see above.  In association with DiChito Builders in South Charlotte, we were able to design and build this addition per the client's specification and it turned out great.  We'll be adding finished photos of the house soon, so stay tuned and you'll see the new addition in the construction phase in the upcoming months.  .

Project Location:

Yadkinville, North Carolina

Residential Designer:

3DFX Solutions Huntersville, North Carolina

Project Description:

This 70's style ranch home is where I was raised and my parents always wanted a new kitchen ever since they moved into the house in the late 80's.  So, I took some dimensions, drew the plans for a new kitchen and created this rendering.  They recently finished the project, as you will see in the slideshow below.  I removed the bar and overhead cabinets and opened the kitchen up into the small dining area and made it an eat-in kitchen.  There was once a wall behind the chairs you see in the rendering and it was removed to open the kitchen up into the formal living room. So, although the house was designed and built in the late 70's, it's now more up-to-date with a 21st century open concept feel.
